Description
- Power: 15W/ 20W/ 25W/ 30W/ 40W/ 50W/ 60W/ 72W/ Selectable
- Dimmable: 0-10V Dimmable
- CCT:3500K/ 4000K/ 5000K/ 5700K/ 6500K/ Selectable
- Beam Angle: 120
- Mounting: Ceiling Installation, Suspension Rod
- Features:
- Led Illuminated Panel Light
- Recessed Led Panel Luminaire
- Slim Led Panel Light
Specifications
| Voltage | 120V-277V/120-347V |
| Beam Angle | 120° |
| CCT | 3500K/ 4000K/ 5000K/ 5700K/ 6500K/ Selectable |
| Power | 15W/ 20W/ 25W/ 30W/ 40W/ 50W/ 60W/ 72W/ Selectable |
| Chips | SMD2835 |
| Power Factor | >0.9 |
| Luminous Flux | 130LM/W |
| Flicker Free | No Flicker |
| Additional Accessories | Emergency Driver |
| Warranty | 5 year limited |
Download Product Cut Sheet
Knowledge Base
What is a troffer panel?
A troffer is a rectangular or square light fixture that typically fits into a modular dropped ceiling grid, often described as “recessed.” Historically, troffer fixtures have been designed to accommodate standard fluorescent lamps like T12 or T8 bulbs. However, now troffer lighting is available in LED.
What is the difference between a troffer and panel?
The primary difference between LED flat panel lights and troffers is that flat panels will seamlessly lay into drop ceilings for a sleek, unobtrusive appearance, while LED troffer fixtures can be installed directly on the ceiling, with a less low-profile aesthetic.
Where are troffer lights used?
Troffers are typically used in commercial applications, but can be used in garages, utility rooms, and basements with dropped ceilings. They distribute light downward, but vary greatly in the spread of the light distribution pattern.
How long do LED flat panels last?
The industry standard for LED lifespan is 100,000 hours, or about 10 years, and most people assume that’s how long their display will last.
Are LED panel lights good?
LED panel lights are some of the most efficient lighting options in the market. They have grown in popularity and are used widely because of their energy-efficiency, and can save more than 80% of energy while producing brighter and softer light than their traditional counterparts.
Are LED panel lights dimmable?
Flat panel dimmable LED lighting systems are just like natural lighting. Dimming gives you control over just how soft and cool you prefer the room to be – making it great for adjusting to performance in classrooms, offices, warehouses and more.
How do LED flat panel lights work?
Current LED flat panel lights are typically designed by using edge-lit backlight theorem, light is transmitted from an LED array to a central area of an edge-lit panel through light guides. Edge-lit LED panels are becoming an extremely popular technology used in indoor lighting fixtures.
How far apart should troffer lights be?
To determine how far apart recessed lighting should be, divide the height of the ceiling by 2 and use that as your light spacing.
Which is better panel light or downlight?
A panel light is good at ambient lighting and can illuminate a room with even, shadowless light. Downlights are easily used as spotlights to create a focal point. Wall-mounted panel lights are ideal for reading light.
What are the benefits of using LED panel lights?
LED light panels will make your business more “green” and eco-friendly. Also, LED lighting is more energy-efficient than fluorescent lighting. Even with greater light quality, LEDs lose less energy and use less electricity. Plus, energy savings correlates to saving money.
